Oluşturulan mesh'leri pürüzsüzleştirerek, incelterek veya rafine ederek, delikleri doldurarak veya eğrilik çizgilerini çıkararak düzenleyebilirsiniz. ZEISS INSPECT, işlem durumunu bir önizleme penceresinde gösterir. Ayrıca en iyi mesh bulunarak veya ortalama mesh ağ hesaplanarak altın bir mesh belirlenebilir. Mesh düzenlemesinden sonra CAD dosyalarını içe aktarabilir ve 3D muayenenize başlayabilirsiniz.
Muayene sonuçlarını en iyi şekilde sunun
Sonuçlarınızı rapor sayfası olarak kaydetmek için doğrudan muayene arayüzünü kullanabilirsiniz. Önceden tanımlanmış sayfa düzenleri ile kapak sayfasını ve içindekiler tablosunu kolayca oluşturabilir veya bir sonucun grafik veya tablo olarak görüntülenip görüntülenmeyeceğini seçebilirsiniz. Raporun içindekiler sayfasından 3D görünümü de geri yükleyebilirsiniz, ZEISS INSPECT daha sonra muayene görünümüne geçer.
ZEISS INSPECT'in sunum moduyla sonuçlarınız bir toplantıda gösterilmeye hazırdır. Rapor sayfalarını tam ekran görüntüleyebilir, raporda gezinebilir ve ilgili 3D görünümü döndürebilirsiniz.
Kullanıcı arayüzünde sonuçlar görüntülenebilir, düzenlenebilir ve pdf belgesi olarak dışa aktarılabilir. PDF belgelerde video şeklinde aşama karşılaştırmaları da gösterebilirsiniz.
ZEISS INSPECT Profesyonel lisansı ile daha fazla imkan
Özel şablonlar oluşturun
ZEISS INSPECT'in Pro lisansı ile kendi raporlama şablonlarınızı oluşturabilir, her sayfaya şirket logonuzu ekleyebilir veya başka tasarım düzenlemeleri yapabilirsiniz. Mevcut şablonlarda değişiklik yapmak da mümkündür.
Çok daha fazla ZEISS INSPECT fonksiyonu
CAD içeri aktarımından farklı denetim ve raporlamalara kadar ZEISS INSPECT'in
en çok tercih edilen fonksiyonlarını sizin için özetledik. Hepsini zaten biliyor musunuz?
